UR-222D

Dual Channel Wireless Receiver
Main Frame Size:EIA standard 1U Channels:Dual Channel Frequency Stability:±0.005%(-10℃~50℃) Carrier Frequency Range:521.25MHz-936.85MHz Modulation Mode:FM Oscillation PLL:synthesized Sensitivity:S/N>60dB at 25 deviation Bandwidth:32MHz Max Deviation Range:±45KHz S/N:>105dB T.H.D:<0.7%@1KHz Frequency Response:80Hz-18KHz ±3dB Operating Range:80M typical(in open space) Power Supply:DC 12V/12W Dimension(mm):410(W)x206(D)x43(H) Weight Approximately:1.9kg

UR-222D Series of condensed the technology essence that Relacart accumulated over a long period. With advanced technology, sophisticated design, stable performance, with beautiful appearance, convenient operation and attractive price, with superior professional quality to win the market competition. This series is suitable for the nightclub of high requirements, multi-functional hall, hotel, conference room and small to medium performance.

Product Description

UR-222D Series of condensed the technology essence that Relacart accumulated over a long period. With advanced technology, sophisticated design, stable performance, with beautiful appearance, convenient operation and attractive price, with superior professional quality to win the market competition. This series is suitable for the nightclub of high requirements, multi-functional hall, hotel, conference room and small to medium performance.

Performance Introduction

Generality

134MHz broadband transmitter, the machines of four different frequency bands can be used interchangeably at will, which is convenient for debugging and management.


IR Infrared Pairing

With [IR] infrared automatic frequency matching function, as long as the [SYNC] button is pressed, the transmitter can automatically and accurately lock the working frequency of the receiver.


Ultra Wide Bandwidth

Ultra-wide frequency band UHF 522MHz~936 MHz, automatic frequency selection, CPU smart antenna diversity reception: 32 adjustable frequency points per channel, 64 adjustable frequency points in total for two channels, a total of 24 frequency bands can provide 768 adjustable frequency points for users to choose.


Anti-Interference

The stable PLL phase-locked oscillation circuit, combined with the "noise detection" mute control function, can effectively block the noise and radio frequency interference in the working environment.


Environmental Protection and Energy Conservation

Precise low-power circuit design makes the battery life twice as long as that of ordinary microphones.


[AFS] Automatic Frequency Search

With [AFS] automatic search channel function, after pressing the [AFS] key for seconds, it will automatically search and lock on an undisturbed working channel.


Technical Specifications

Main Frame Size: EIA standard 1U

Channels: Dual Channel

Frequency Stability: ±0.005%(-10℃~50℃)

Carrier Frequency Range: 521.25MHz-936.85MHz

Modulation Mode: FM

Oscillation: PLL synthesized

Sensitivity: S/N>60dB at 25 deviation

Bandwidth: 32MHz

Max Deviation Range: ±45KHz

S/N: >105dB

T.H.D:<0.7%@1KHz

Frequency Response: 80Hz-18KHz  ±3dB

Operating Range: 80M typical(in open space)

Power Supply: DC 12V/12W

Dimension(mm): 410(W)x206(D)x43(H)

Weight: Approximately 1.9kg

Support

Product Brochure

UR-222D-brochure
