RF carrier frequency range: 521.25MHz-936.85MHz
Frequency stability: 0.005%
Effective working distance (ideal environment): ≥80 meters
Audio companding: DSP digital audio companding
Audio frequency response: 50Hz-1600Hz ±3dB
Dynamic range: 85 dB
Signal-to-noise ratio (A-weighted): 80 dB
Total harmonic distortion: ≤1%,@1KHz
Operating temperature range: -10℃ ~ +50℃
Receiving bandwidth: 470MHz~960MHz
Receiving method: superheterodyne
Image rejection: 45dBm
RF sensitivity: when inputting 10dBu, S/N ≥ 45dB;
Squelch adjustment: built-in setting parameters;
Frequency synchronization method: manual key setting
Maximum output level: LINE: 0.5Vpp; Phone: 1Vpp
Output level adjustment range: 30-level adjustable, attenuated adjustment, every 2dB step;
Output impedance: 400Ω
Power supply: AA 1.5V x 2
Normal working current: 3V 150mA
Battery usage time: ≥8.5 hours
Dimensions (mm): 95 x 65 x23
Net weight (without battery): 100g
