UR-290 Receiver
Chassis specification: EIA standard 1U
Receiving channel: Dual channel
Frequency stability: ± 0.005%
Carrier frequency band: 521.25MHz-936.85MHz
Modulation method: FM
Sampling rate: 96K
Oscillation mode: PLL frequency synthesis technology
Sensitivity: When the offset is equal to 25KHz and 5dBuV is input, S/N>60dB
Band width: 64MHz (depending on region)
Maximum offset: ± 45KHz
Comprehensive S/N ratio:>110dB
Comprehensive T.H.D:<0.5% @ 1KHz
Frequency response: 50Hz-18KHz ± 1dB
Effective working distance: generally 100 meters (wide range)
Power supply: DC12V/1A
Dimensions (mm): 410 (length) x 206 (width) x 43 (height)
Antenna interface: Dual BNC supports+12V/150mA
Output audio interface: 6.3mm unbalanced audio output, XIR balanced audio output
Interface: Dante Network Protocol
Weight: Approximately 2 kg
