Main Frame Size：EIA Standard Rack 1U
Receiving Channel：Dual Channel /Single Channel
Receiving Mode：True Diversity
Frequency Reliability：±0.005%(-10-50°C)
External Antenna Interface：BNC,DC 12V/150mA output
External Audio Interface：Mixed 6.35mm unbalanced ,independent channel XLR output
Ethernet Port：Support Dante communication protocol
Receiving Frequency Band：521.25MHz-936.85MHz
Working Mode：PLL frequency synthesis oscillation and secondary mixing reception technology
Receiving Sensitivity：When the offset is equal to 25KHz and 5dBu is input, S/N>60dB
Bandwidth：Single channel 130MHz（depending on the region）
Max. Deviation：±45KHz
Audio Sampling Rate：96KHz 24-bit
Audio Extension：Relacart DSP digital audio extension algorithm
Comprehensive S/N：>105dB
Comprehensive T.H.D：<0.7%@1KHz
Frequency Response：50Hz-18KHz±3dB
Working Range：100M Typical(in open space）
Power Mode：AC 100~240V , 50/60Hz
Dimension(mm)：480(W)x350(D)x43(H)
Weight : Approximately 1.8KG
