MC2

2.4G Wireless Microphone System

The MC2 wireless microphone system uses ISM global unlimited 2.4G frequency band for transmission.The receiver and transmitter can automatically pair after power-on.Equipped with noise reduction function to reduce surrounding noise.The back clip of MC2 adopts a magnetic silicone design, greatly improving user convenience,and is equipped with a shoe base specifically designed for the camera, making MC2 more securely connected to the camera.Suitable for digital/DSLR cameras, camcorders, video recorders, tablets, mobile phones, and other devices.

Product Description

The MC2 wireless microphone system uses ISM global unlimited 2.4G frequency band for transmission.The receiver and transmitter can automatically pair after power-on.Equipped with noise reduction function to reduce surrounding noise.The back clip of MC2 adopts a magnetic silicone design, greatly improving user convenience,and is equipped with a shoe base specifically designed for the camera, making MC2 more securely connected to the camera.Suitable for digital/DSLR cameras, camcorders, video recorders, tablets, mobile phones, and other devices.

Details

Connection diagram

Frequency Response

Polar Pattern

Specifications

Package Contents

System Technical Specifications:

Transmission frequency band:2400MHz~2483.5MHz

Audio frequency response:100Hz-18KHz±3dB

S/N:85dB (Circuit performance)

SPL:100dB(built-in microphone)

Pairing type:Automatic

Effective working distance:100m(in a spacious place)

Working temperature Range:-5℃~-+50℃

Receiver Technical Specifications:

Transmission Frequency Band:2400MHz~2483.5MHz

Transmission type: frequency hopping/digital FSK

Receiving sensitivity:-86dBm

Antenna: built-in PCB antenna

Display: multifunctional OLED display

Power supply requirements: Built in lithium battery, standard USB 5V charging through TYPE-C interface.

Battery life: > 6 hours

Output interface: 3.5mm TRS, Type-C digital output

Working temperature:-5℃~-+50℃

Maximum charging current: 270mA/H

Charging time: ≤ 2 hours

Dimensions: 67 x 32 x 13.5 ( mm )

Weight: 26.8g

Transmitter Technical Specifications:

Transmission Frequency Band:2400MHz~2483.5MHz

Transmission type: frequency hopping/digital FSK

Transmission power: 10dBm

Antenna : built-in PCB antenna

Microphone pickup type: omnidirectional (built-in microphone)

Display: multifunctional OLED display

Power supply requirements: Built in lithium battery, standard USB 5V charging through TYPE-C interface.

Battery life:  ≥ 6 hours

Input interface: 3.5mm TRS

Working temperature:-5℃~-+50℃

Maximum charging current: 270mA/H

Charging time: ≤ 2 hours

Dimensions: 67 x 32 x 13.5 ( mm )

Weight: 27.4g

Support

Operation manual

MC2V1.0(230308)
